Features
· Visible Light Facial Recognition
· Anti-spoofing algorithm against print attack (laser, color and B/W photos), videos attack and 3D mask attack
· Multiple verification methods: Face / Fingerprint / Card / Password
· Available card modules: 125KHz ID card (EM) / 13.56MHz IC card (MF)
· Supplement light with adjustable brightness
· 6,000 face templates capacity
2 meters of recognition distance and extra wide angle recognition
The recognition distance has been greatly extended to 2 meters, which significantly improves maximum traffic rate. While most of the algorithms only support +/-15° of detectable face angle, SpeedFace-V5L doubles the detection angle in terms of head rotation and tilt to +/- 30°.
Specification
| Display | 5” touchscreen |
| Face Capacity | 6,000 |
| Fingerprint Capacity | 6,000 (Standard); 10,000 (Optional) |
| Card Capacity | 10,000 |
| Transactions | 200,000 |
| Operation System | Linux |
| Standard Functions | ID Card, ADMS, T9 Input, DST, Camera, 9-digit User ID, Access Levels, Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm, Multiple Verify Modes |
| Hardware | 900MHz Dual Core CPU; 512MB RAM / 8G Flash; 2MP WDR Low Light Camera; Adjustable LED Supplement Lighting |
| Communication | TCP/IP, WiFi (Optional), Wiegand input / output, RS485 |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm output, Auxiliary Input |
| Optional Function | 13.56MHz IC Card (MF) |
| Facial Recongntion Speed | ≤1s |
| Biometrics Algorithms | ZKFace V5.8 & ZKFinger V10.0 |
| Power Supply | 12V 3A |
| Working Humidity | 20%-80% |
| Working Temperature | 0°C ~ 45°C (32°F ~ 113°F) |
| Dimensions (WHD) | 91.93 * 202.93 * 21.5 (mm) |
| Supported Softwares | ZKBioAccess |
Support ZKBio Access IVS
ZKBio Access IVS is a lite web-based security platform developed by ZKTeco which supports most ZKTeco Hardware. It provides abundant functionality that fulfills management requirements of small- to medium-sized businesses: Personnel Management, Access Control, Attendance Management, Video Surveillance, System Management.
Features
• Web-Based Attendance Module
• Supports T&A devices with ADMS function
• Supports setup of attendance points on A&C devices to generate T&A logs
• Supports language switching in real-time
• Supports HTTPS protocol for data security
• Stable, fast and consistent communication
• Alarms and events email notification
